Automotive Certified High-Performance Lithium-Ion Battery Systems

Battery Systems

AKM CYC - Ultra High-performance Technology For Ultra High Energy Applications

  • Cylindrical cells (CYC)
  • Very high energy density
  • Robust and scalable
  • Medium to high cycle life

Application focus

  • Long-range applications
  • Medium power applications

View Battery Details

More Power at Less Space

With very high energy densities on system level and in our view the most compact liquid cooling, our battery systems have very low space requirements and emit only little heat. These are the ideal preconditions for a long battery life with a high power output for a safe, reliable and durable operation.

Serial Production According to IATF 16949

To fulfill our clients‘ automotive standards, our battery systems for bus applications are developed and produced in an automotive IATF 16949 compliant environment at our headquarters in Darmstadt/Germany. And where necessary, we fulfill additional, project-specific requirements.

Flat Module Architecture (FMA)

Flat Module Architecture will play a major role in the future light to heavy duty commercial vehicle market. The modular concept with a voltage range of 350V - 750V, usable energy of up to 50kWh within a flat architecture ensures to serve the wide range requirements of the market with the highest energy density.

System Benefits

  • Opportunity to place the packs in subfloor architectures
  • perfect match to various space requirements
  • Upcoming technology leadership* in terms of energy density
*Battery systems with flat module architecture


Intelligent solutions for all areas of eMobility


  • Prismatical cells (PRC)
  • High energy technology
  • Compatible with standardized PHEV modules of all major OEMs

Application focus

  • Medium cycle applications
  • Mid-range applications
  • Fast charging compliant

View Battery Details


  • Prismatical cells (PRC)
  • Very high energy and power density
  • Flexible scalability
  • High cycle life

Application focus

  • 48V applications
  • Small electric vehicles and marine

View Battery Details


More Energy for the Long Haul

The ultra high energy battery system AKA CYC uses the new cylindrical cell battery modules with very high energy density. It’s robust and scalable, and acquisition costs per kWh are comparatively low. In comparison to what current technology permits, this new technology will allow electric vehicles to increase their range by more than 60 percent. This system is developed for long-distance traffic, e.g. buses using overnight charging facilities, intercity coaches and trucks.


21,700 standard battery cells


Designed and validated for auto­mo­tive serial applications


Longterm technology roadmap based on standardized cells

AKM CYC - High-performance Technology for Ultra High Energy Applications

Battery Systems
Technical Data AS 9AKM 150Ah CYC
Energy (nominal)*** 98 kWh
Weight (typical)* ~ 554 kg
Discharging power cont.** 100 kW
Charging power cont.** 80 kW
Capacity (nominal)*** 147 Ah
Voltage nom. 665V
Cycle life (for typical usage profile) 4,000 cycles
Dimension (L x H x W) in mm 1,720 x 700 x 300
* Depending on housing material
** Depending on cable, connector, SOC, temperature and internal fuse type
*** Nominal energy and capacity of the battery system, based on the datasheet of the cell supplier at 0.2C charge rate and room temperature. This energy content is underlying natural degression because of unavoidable chemical processes, including calendric and cyclic aging of the cells. The cell aging is dependent on usage parameters like temperature, power, state of charge and energy throughput over time.


Certified According to Automotive Standards

The latest OEM lithium-ion battery system proves: powerful, specifically adapted lithium-ion battery systems for commercial vehicles can be both high-quality and affordable at the same time. The system is compatible with the standardised PHEV modules of all major OE manufacturers. Even commercial vehicles for series production are ideally equipped for their demanding tasks and, at the same time, remain flexible should the module supplier change at any point.



Automotive PHEV battery modules


Designed and validated for auto­mo­tive serial applications


Longterm technology roadmap based on standardized modules


15 OEM 50 PRC
Technical Data AS 150OEM 50Ah PRC
Energy* 33 kWh
Weight (typical)**** 254 kg
Discharging power max.** 150 kW
Charging power max.** 100 kW
Continuous power discharge (RMS)** 50 kW
Continuous power charge** 45 kW
Capacity* 50 Ah
Voltage nom.* 665V
Cycle life*** >3,000 cycles
Dimension (L x H x W) in mm 1,700 x 700 x 150
* 0,33C reference discharge cycle
** Depending on SOC and temperature
*** Depending on individual use profile, especially DoD, temperature and power
**** Depending on housing material


Technology for Flexible Applications

The AKARack is revolutionary due to its characteristics – it offers very high energy and power density in combination with its flexible scalability. Thus, it is the ideal solution for applications in a power range from 5 kW to approx. 50 kW.

With 6.6 kWh to 40 kWh in stored energy, it is outstanding for use in industrial and construction machinery, such as small excavators or front loaders, as well as in the 48V on-board power supply system in commercial vehicles, and even for small boats. If output of more than 50kW or even more energy is required, the 48V systems can also be operated as a AKASystem AKR PRC in parallel.

Integrated contractor, fuse & voltage monitoring


Serial or parallel connection possible

Liquid and air cooling is possible

50 PRC - The Flexible Energy Pack

15 OEM 50 PRC
Technical Data AKARack Base Unit 150 Ah
Energy* 6.6 kWh
Weight (typical)**** 56 kg
Discharging power max. (10 s)** 9 kW
Charging power max. (10 s)** 9 kW
Continuous power (RMS) > 15min** 5.5 kW
Capacity* 150 Ah
Voltage nom.* 44 V
Cycle life**** > 3,000 cycles
Dimension (L x H x W) in mm**** 590 x 446 x 133
* 0,33C reference discharge cycle
** Depending on SOC and temperature
*** Depending on individual use profile, especially DoD, temperature and power
**** Masterbox specification: similar dimensions, weight typically 30 kg
